The RGBW LED Flex Strips are our first strip offering color changing + white LEDs. This top of the line strip combines two powerful strip lights into one: alternating RGB color changing LEDs plus single-color high brightness white LEDs. This LED strip is for those spaces that you want total control over, the lights mix to make any color you can imagine including a quality warm-white when you need it. The strips are easy to use, making it possible to install with minimal knowledge on the electrical side. The flexible construction of the strip combined with the 3M adhesive backing and cut-to-size design make it convenient to elevate any indoor space.
Controlling Colors
In order to run RGBW Flex Strip you will need the RGBW Touch Controller (sold separately).
Features
- Color Changing + Whites!
- 30 LEDs per FT!
- 12mm wide
- Lengths: 3 Ft. - 16.4 Ft. (Full Reel)
Details
| LED Density: High Density - 96 LEDs/M | Colors: Color-Changing RGB + Warm White 3000K |
| LEDs: Alternating 3-in-1 RGB + White LEDs | Power: 24VDC |
| Wattage: 23 Watts/M (115/Reel) | Mounting: Doubled-Sided 3M Tape |
| Cuttable: Every 12 LEDs (4.92") | Custom Lengths: 3-Foot Increments up to 16.4-Feet (Full Reel 5M) |
| Size: 12mm Wide X 1mm Tall | Connection: 5-pin RGB+W connector |
Lengths
To avoid buying more than necessary we offer custom length LED light strips in 3-foot increments up to 16.4 feet long (1 full reel). However, we realize that all applications have different needs which is why the strips can be cut after every 12 LEDs which equates to ever 4.92". There is a thin black line over solder pads, which marks where you are to cut the strips. Max Run Length = 1 full reel - 16.4ft.
End-to-End Connections
When there is a break in your application you can still run one strip to another using 20-24 gauge wire or LED strip connectors. TAKE NOTE: the RGBW Strips maximum run length is 16.4 feet (1 reel). After the maximum run length the voltage drop becomes too great and you will lose light and efficiency from your system. If your application needs more than the maximum run length you will have to get another power supply or run wire from the extra strip directly back to the first power supply (wiring in parallel).
Connections can be made by soldering wire in between strips or by using solderless clamps (see right). Only one end of the strips come with a 5-Pin connector on it so if you want to make more connections you will need to solder or use strip connectors .
Power
A 24-volt DC Power Supply is required to run these LED Strip lights (along with an RGBW controller). The Strips run at 23W per meter, so a full reel is 115 Watts of power. Please make sure you get a Power Supply suitable enough for your needs.
